Does anyone know anything about the "new" infotainment system AIO_2021_W1 (ecuType)? It's a AIO (All-In-One, 10" touchscreen+head unit) from Bosch - all other RCC AIO and NAC AIO are from Continental. It's present in some recent (2024) models of the e-208 facelift and e-2008 facelift, and it has a 10" touchscreen without satnav (up until now, those were the basic version of the IVI infotainment system, "Peugeot i-Connect", and the "Peugeot i-Connect Advanced" with satnav).

Found 2 firmware versions:

{
  "updateType": "aio-firmware",
  "updateVersion": "1_024_2022.16.2",
  "updateProvider": "BOSCH_CAR_MULTIMEDIA",
  "updateId": "005325451650900692",
  "updateDate": "2022/06/03 13:55:28",
  "fileName": "PSA_aio-firmware_1_024_2022-16-2_AIO_2021_W1.tar",
  "updateStatus": {
    "code": "PUB",
    "label": "Publié"
  }
}

{
  "updateType": "aio-firmware",
  "updateVersion": "2_036_2023.20.1",
  "updateProvider": "BOSCH_CAR_MULTIMEDIA",
  "updateId": "005325451685684506",
  "updateDate": "2023/06/02 07:46:44",
  "fileName": "MJBSU_aio-firmware_005325451685684506.tar",
  "updateStatus": {
    "code": "AVC",
    "label": "En attente de validation fournisseur"
  }
}

Those .tar files have about 2.4 GB.

Or expired certificates.

Could you please download the PSA online certificates from http://pki.p3cs.com/PSA-OVIP-G1.crl , http://pki.p3cs.com/PSA-OVIP-CS-G1.crt and http://pki.p3cs.com/PSA-OVIP-CS-G1.crl and replace the same files in the USB flash drive folder/directory "\SWL\00131503*\Certificates\", and try again?

That's only the OSS (Open Source Software) used in the firmware, to comply with the BSD/GPL or other OSS licenses from those packages.

A NAC Wave 2 (common in 2017) with an older 5.x.x.x version also doesn't have Google Android Auto support, that was only added in 21.x.x.x firmware versions.

If that's the case, a firmware update could fix that.

Zitat von MiRuDa

Zitat von rui.saraiva

expires at Nov 3 14:38:04 2024 GMT.

can that be true?

2024?

> openssl smime -in MediaHeader/MediaVersion.ini -pk7out | openssl pkcs7 -print_certs -text | head
Certificate:
    Data:
        Version: 3 (0x2)
        Serial Number: 14 (0xe)
        Signature Algorithm: sha256WithRSAEncryption
Issuer: C=FR, L=Paris, O=PSA Peugeot Citroen, OU=Certificate Authorities, OU=(c) PSA Peugeot Citroen - For authorized use only, OU=0002 319187308, CN=PSA - OVIP - Code signing - G1
        Validity
            Not Before: Nov  3 14:38:04 2021 GMT
            Not After : Nov  3 14:38:04 2024 GMT
        Subject: C=FR, L=Paris, O=PSA Peugeot Citroen, OU=Open Vehicle Infotainment Platform, OU=(c) PSA Peugeot Citroen - For authorized use only, CN=Continental \/ NAC \/ 1

Older versions have expired digital certificates, so you can't install them.

The latest NAC Wave 2 firmware version, 21.08.87.32_NAC-r1, expires at Nov 3 14:38:04 2024 GMT.

And those aren't the release dates, but compilation dates.

The correct link is https://ds4emloty3shq.cloudfro…-3I37-1_RCC_EU_W3_ECO.tar

Shaeded : BTW, if you install that version, could you please confirm the HMI, iMX and V850 versions?

So there's something else. I've a 3008 (NAC Wave 2) and a e-208 (NAC Wave 4), both with a AAWireless dongle. The former needs to be connected on the factory USB port but the later can be connected in either port.

byrrt: You have a NAC Wave 4 and on NAC systems the code is "1111". But you just have to connect the cable and that's it.

The engineering/expert menu on NAC systems is only for spylogs and cheat codes, there isn't much to tinker with.

edu_chirimoya : On Wave 3/4 systems, both USB ports should work for AA and CP.

edu_chirimoya:

Not sure. I've read somewhere that only one phone call could be done through bluetooth and after that you have to restart the system to make another one...

{
  "updateType": "rcc-firmware",
  "updateVersion": "6_0421_23.3I29.1",
  "updateProvider": "BOSCH_CAR_MULTIMEDIA",
  "updateId": "005315191690542113",
  "updateDate": "2023/09/07 10:03:31",
  "updateStatus": {
    "code": "AVC",
    "label": "In consideration of supplier validation"
  }
}

The firmware version 6_0421_23.3I29.1 for RCC Wave 3 was withdrawn, but because you can't downgrade the firmware, you're stuck to that version until Bosch/PSA releases a new one.

You can have partitions larger than 32 GB in FAT32, Windows might not be able to format it (with the GUI), but can read/write them without problems. The NAC/RCC can also read those bigger-than-32GB FAT32 partitions without problems.

Those are only FM logos. DAB logos are transmitted by the respective stations. So, BerndP, maybe you're talking about DAB...

Zitat von jurabln

Zitat von rui.saraiva

The FM logos are stored in the Firmware/AUTO/1010121 folder, in the radio-app-data-resource.tar.gz (encrypted) file. That file is then extracted to a media/datastore/radio/stationLogos// directory in a live system. Depending on the firmware version, there are 2 logos for each station (png and tga image files) or just png files, all with the same 256x256 resolution. The filename of each logo is just the Programme Identification (PI) a 4 digit hex number that is broadcasted through Radio Data System (RDS). For Austria (AUT) the latest NAC Wave 4 firmware has this logos:

Hallo, ich wohne in Berlin und habe einen Toyota Proace Verso mit einem NAC wave4. Ich empfange so gut wie gar keine Senderlogos ... hat jemand die Liste der deutschen Sender welche in der Firmware hinterlegt sind?

Here it is, from firmware 44.07.05.22_NAC-r0:

Zitat von j23

Zitat von Mittns

'''

Even though PSA has never complained in any way since years in several websites. ''''

that's what i mean no one care about and private key used to pack is not know so not possible to get(make-hack-rebulid) a custom build FW ..... din't posted genuine link as don't wona have it blocked in the future.....

I removed the (recent) "fileName" JSON entry from the getUpdateStatus reply for the same reason, it gives too many clues for the full URL and the generic format for future ones.

I also don't see the point of sharing that beta software. The "final" versions already have enough bugs and it isn't easy to rollback a firmware. That version might also not be the final version anyway, there are many versions in AVP status that were never released (44.06.44.22_NAC-r0, 44.06.42.32_NAC-r0, 44.05.33.42_NAC-r0, 44.04.25.52_NAC-r0 or 44.03.20.32_NAC-r0, just to name a few of the recent ones and there are 3 other versions after the last public release in testing state - this one for instance:

{
  "updateType": "ovip-int-firmware-version",
  "updateVersion": "44.07.30.52_NAC-r0",
  "updateProvider": "CONTINENTAL",
  "updateId": "001315031690989825",
  "updateDate": "2023/08/03 09:40:38",
  "updateStatus": {
    "code": "AVC",
    "label": "En attente de validation fournisseur"
  }
}

It was "released" just a few days before 44.07.33.32_NAC-r0.

Also in the context of those unreleased (to public) versions, many are just partial updates and not full upgrades. For instance this one:

{
  "updateType": "ovip-int-firmware-version",
  "updateVersion": "43.04.27.02_NAC-r0",
  "updateProvider": "CONTINENTAL",
  "updateId": "001315031643204228",
  "updateDate": "2022/02/16 20:22:40",
  "updateStatus": {
    "code": "AVP",
    "label": "En attente de validation PSA"
  }
}

Has only 40.960 bytes, and it's in AVP state. I'll bet that installing this one in the incorrect base version, and you'll have a nasty surprise.

seanyp99 : It won't happen. In the NAC Wave 4, the area for apps (including Android Auto and CarPlay) it's designed to be 1280x620 in the 1920x720 10" wide HD display. The new UI with the Android Auto and CarPlay in full screen, only in the new infotainment system hardware, IVI.

brandwacht That firmware is still in testing state, unreleased to public.

{
  "updateType": "ovip-int-firmware-version",
  "updateVersion": "44.07.33.32_NAC-r0",
  "updateProvider": "CONTINENTAL",
  "updateId": "001315031692686757",
  "updateDate": "2023/09/21 10:36:56",
  "updateStatus": {
    "code": "AVP",
    "label": "En attente de validation PSA"
  }
}

edu_chirimoya:

No, that's only about connected services - NAC Wave 2 also have that message.

The 44.07.33.32_NAC-r0 version (UpdateID 001315031692686757) was released in August and is still in AVP state.

Did you use a macOS to prepare the USB flash drive? If so, run the CleanMyDrive 2 app before ejecting the drive.

arfe The e-2008 could have a RCC Wave 3, NAC Wave 2 or Wave 4 (with the 10" HD touchscreen). And the facelift version the IVI infotainment system.
